Product specifications:

ORIGINAL SCREEN

市 场 价:¥0

优 惠 价:¥0

库  存:999

选择商品:

商品详细

Original screen: in view of the original factory production of main products, brands include: the innolux, AUO, IVO, BOE,TCL, CPT fittings etc series products. Product stability, universality, versatility is stronger. Welcome customers to choose!

Details

Original screen: in view of the original factory production of main products, brands include: the innolux, AUO, IVO, BOE,TCL, CPT fittings etc series products. Product stability, universality, versatility is stronger. Welcome customers to choose!

  • Size Brand Part No. Resolution L (cd/m^2)(TYP) OperatingTemp(℃) Description Remark Inquiry Download
    3.5 INNOLUX LQ035NC111 320x240 300 -20~70 TN ,50pin/ 8bits/TTL/存储-30~80
    4.3 INNOLUX AT043TN24 V.7 480×272 500 -20-70 a-Si TFT-LCD/RGB/40PIN 存储-30-80
    4.3 INNOLUX AT043TN25 V.2 480×272 500 -20-70 a-Si TFT-LCD/RGB/40PIN 存储-30-80
    5.6 INNOLUX AT056TN52 V.3 640x480 200 -20~70 50pin 4:3/存储-30~80TN LCD / TTL
    7.0 INNOLUX AT070TN83 V.1 800x480 300 -20~70 TN LCD W / LED, 6bits/TTL
    7.0 INNOLUX AT070TN92 800x480 250 -20~70 TN/16:9/ 6/8bits/TTL//50PIN 存储-30-80
    7.0 INNOLUX AT070TN94 800x480 400 -30~85 TN/8bits/RGB/50pin /16:9/存储-30~80
    8.0 INNOLUX AT080TN64 800x480 450 -30~85 TN/8bits/TTL/16:9/50PIN 存储-30-85
    8.0 INNOLUX EJ080NA-05B 800x600 250 -20~70 TN / 6/8bits/TTL/4:3/50PIN 存储-30-80
    5.7 INNOLUX G057VGE-T01 640x480 450 -30~85 TN LCD / LED, 6 bits/TTL
    7.0 INNOLUX G070ACE-L01 800x480 500 -30~85 AAS LCD W / LED, 6/8bits/LVDS ReplaceableLQ070Y3LW02
    7.0 INNOLUX G070Y2-L01 800x480 500 -30~85 TN LCD w/ LED, 6/8 bits/LVDS
    7.0 INNOLUX G070Y2-T02 800x480 500 -30~85 TN LCD w/ LED, 6/8bits/TTL Without GAMMA board
    8.0 INNOLUX G080Y1-T01 800x480 600 -30~85 TN LCD w/ LED, 6/8 bits/TTL Without GAMMA board
    10.1 INNOLUX EE101IA-01D 1280x800 NA -20~70 AAS OPEN CELL,8 bits/LVDS
    10.1 INNOLUX G101ICE-L03 1280x800 500 -20~65 AAS LCD w/ LED, 6/8bits/LVDS
    10.4 INNOLUX G104ACJ-L01 960x1280 900 -40~85 AAS LCD / LED, 6/8bits/LVDS
    10.4 INNOLUX G104AGE-L02 800x600 400 -30~85 TN LCD / LED, 6/8bits/LVDS
    10.4 INNOLUX G104S1-L01 800x600 400 -20~70 TN LCD / LED, 6/8 bits/LVDS
    10.4 INNOLUX G104X1-L04 1024x768 500 -30~80 MVA LCD / LED, 6/8 bits/LVDS ReplaceableG104XCE-L01
    10.4 INNOLUX G104XCE-L01 1024x768 500 -30~85 AAS LCD / LED, 6/8bits/LVDS ReplaceableG104X1-L04
    5.0 INNOLUX ZJ050NA-08C 640×480 250 -20-70 a-Si TFT-LCD/RGB/50PIN 存储-30-80
    5.0 INNOLUX AT050TN33 480×272 300 -10-60 a-Si TFT-LCD/RGB/40PIN 存储-20-70
    6.5 INNOLUX AT065TN14 800×480 400 -30-85 a-Si /RGB/16:9/50PIN 存储-30-80
    7.0 INNOLUX AT070TN93 800×480 320 -10-60 a-Si TFT-LCD/RGB/50PIN 存储-20-70
    9.0 INNOLUX ZJ090NA- 03B 800×480 500 -20-80 a-Si TFT-LCD/RGB/50PIN 存储-30-80
    10.2 INNOLUX AT102TN03 V.8 800×480 350 -30-85 a-Si TFT-LCD/RGB/60PIN 存储-30-85
    7.0 INNOLUX NJ070NA-23A 1024x600 500 -20~70 40pin FPC/16:9/ LVDS存储-30~80
    10.2 INNOLUX AT102TN03 V.8 800x480 350 -20~70 60pin FPC/16:9/ RGB存储-30~80
    10.1 INNOLUX NJ101IA-01S 1280*800 500 -20~70 IPS/40pin FPC/16:10/ LVDS存储-30~80 On board front mounted
    8.0 INNOLUX DJ080IA-11A 1280x720 750 -30~85 IPS/40pin FPC/16:9/ LVDS存储-40~90 On board front mounted
    9.0 INNOLUX DJ090IA-01A 1280x720 750 -30~85 IPS/40pin FPC/16:9/ LVDS存储-40~90 On board front mounted
    10.1 INNOLUX DJ101IA-07A 1280x720 750 -30~85 IPS/40pin FPC/16:9/ LVDS存储-40~90 On board front mounted
    10.25 INNOLUX JJ103IA-A7B 1920x720 800 -30~85 IPS/60pin FPC/8:3/ LVDS存储-40~90 On board front mounted
    12.3 INNOLUX JJ123IA-01J 1920x720 750 -30~85 IPS/60pin FPC/8:3/LVDS存储-40~90 On board front mounted
    4.3 INNOLUX AT043TN24 V.7 480x272 400 -20~70 40pin FPC, RGB存储-30~80/TP
    5.0 INNOLUX HE050NA-01U 800x480 NA -20~70 50pin FPC, RGB存储-30~80/FOG
    5.6 INNOLUX AT056TN53 V.1 640x480 350 -20~70 40pin FPC/4:3/ RGB存储-30~80
    7.0 INNOLUX AT070TN83 V.1 800x480 300 -20~70 40pin FPC,/15:9/ RGB存储-30~80
    7.0 INNOLUX LW700AT6005 800x480 NA -20~70 60pin FPC/15:9/ RGB存储-30~80/FOG
    8.0 INNOLUX EE080NA-06A 800x600 NA -20~70 50pin FPC/4:3/ RGB存储-30~80/FOG
    9.0 INNOLUX AT090TN12 V.3 800x480 250 -20~70 50pin FPC/16:9/ RGB存储-30~80
    10.4 INNOLUX ZE104IA-03D 1024x768 NA -30~80 40pin FPC/4:3/ LVDS存储-30~80
    10.1 INNOLUX EJ101IA-01G 1280*800 350 0-50 40pin FPC/16:10/ LVDS存储-20~60
    12.1 INNOLUX G121I1-L01 1280x800 400 -20~80 MVA LCD W / LED, 6/8 bits/LVDS 22 YEAR Q1 EOL
    12.1 INNOLUX G121ICE-L02 1280x800 400 -20~70 MVA LCD W / LED, 6/8 bits/LVDS
    12.1 INNOLUX G121XCE-L01 1024x768 600 -30~85 AAS LCD / LED, 6/8bits/LVDS
    12.1 INNOLUX G121XCE-L02 1024x768 500 -30~70 AAS LCD W / LED, 6/8bits/LVDS
    15.0 INNOLUX G150XNE-L02 1024x768 350 -30~70 VA LCD / LED, 6/8bits/LVDS
    15.0 INNOLUX G150XNE-L03 1024x768 300 -20~70 VA LCD / LED, 6/8bits/LVDS
    15.6 INNOLUX G156BGE-L01 1366x768 300 0~60 TN LCD W / WLED, 8bits/LVDS
    15.6 INNOLUX ZE156IA-02B 1920x1080 NA -20~70 全视角/EDP/30PIN 存储-30-80
    15.6 INNOLUX G156HCE-E01 1920x1080 450 0~60 AAS LCD W / LED, 8bits/EDP
    15.6 INNOLUX G156HCE-L01 1920x1080 450 -30~85 AAS LCD W / LED, 8bits/LVDS
    15.6 INNOLUX N156BGA-EB2 1366x768 220 0~50 TN LCD W / WLED, 6bits/EDP
    17.0 INNOLUX M170EGE-L20 1280x1024 250 0~50 TN LCD / WLED, 8bits/LVDS
    20.0 INNOLUX M200HJJ-L20 1920x1080 250 0~50 MVA LCD W / LED, 8bits/LVDS
    21.5 INNOLUX M215HJJ-L30 1920x1080 250 0~50 MVA LCD W / WLED, 8bits/LVDS
  • Size Brand Part No. Resolution L (cd/m^2)(TYP) OperatingTemp(℃) Description Remark Inquiry Download
    10.1 AUO A101VW01 V.3 800x480 300 -10~60 TN LCD w/ LED, 6bits/TTL
    10.4 AUO A104SN03 V.1 800x600 300 -10~60 TN LCD / LED, 6/8bits/TTL
    5.7 AUO G057VN01 V.2 640x480 700 -30~85 TN LCD / LED, 6bits/TTL
    6.5 AUO G065VN01 V.2 640x480 800 -30~80 TN LCD / LED, 6bits/LVDS
    7.0 AUO G070VW01 V.0 800x480 400 -30~85 TN LCD W/ LED, 6/8bits/LVDS
    8.4 AUO G084SN03 V.3 800x600 250 -20~70 TN LCD/ LED, 6/8bits/LVDS
    8.4 AUO G084SN05 V.9 800x600 450 -30~85 TN LCD/ LED, 6/8bits/LVDS
    10.1 AUO G101EVN01.0 1280x800 300 -20~60 MVA LCD W/ LED, 6bits/LVDS
    10.1 AUO G101STN01.2 1024x600 250 -10~60 TN LCD W/ LED, 6bits/LVDS
    10.4 AUO G104SN03 V.5 800x600 230 -20~70 TN LCD / LED, 6/8bits/LVDS
    10.4 AUO G104XVN01.0 1024x768 450 -30~80 PSA LCD / LED, 6/8bits/LVDS
    10.4 AUO G104STN01.0 800x600 400 -30~80 PSA LCD / LED, 6/8bits/LVDS
    15.0 AUO G150XTN06.0 1024x768 450 -30~85 TN LCD / LED, 6/8bits/LVDS
    17.0 AUO G170ETN01.0 1280x1024 350 0~50 TN LCD / LED, 6bits/LVDS
    17.3 AUO G173HW01 V.0 1920x1080 400 0~70 TN LCD W/ LED, 6bits/LVDS
    18.5 AUO G185HAN01.0 1920x1080 350 -20~70 AHVA LCD W/ LED, 8bits/LVDS
    19.0 AUO G190EAN01.0 1280x1024 300 0~50 MVA LCD /LED, 8bits/LVDS Medical screen
    19.0 AUO G190EG01 V.1 1280x1024 350 0~50 TN LCD /LED, 6bits/LVDS
    19.0 AUO G190ETN01.2 1280x1024 350 -30~85 TN LCD /LED, 6bits/LVDS
    14.0 AUO B140HAN03.G 1920x1080 300 -20-60 全视角/PCBA弯折EPD/40PIN 存储-20-60
    14.0 AUO B140HAN04.7 1920x1080 220 0-50 全视角/PCBA弯折EPD/40PIN 存储-20-60
  • Size Brand Part No. Resolution L (cd/m^2)(TYP) OperatingTemp(℃) Description Remark Inquiry Download
    4.3 IVO M043GW32 R0 480x272 550 -20~70 4.3", TN LCD w/ LED, 6/8 bits/TTL
    7.0 IVO M070AWP1 R7 800x480 500 -20~70 7", TN LCD w/ LED, 8bits/TTL
    7.0 IVO M070AWPA R0 800x480 1000 -30~85 7", IPS LCD w/ LED, 8bits/TTL Vehicle gauge instrument
    7.6 IVO E076AWW1 R0 1280x240 -30~80 7.6", IPS LCD w/ LED, 8bits/LVDS
    8.0 IVO M080AWP9 R5 800x480 750 -40~85 8.0", TN LCD w/ LED,TTL Vehicle regulation central control
    8.4 IVO M084GNS1 R1 800x600 350 -20~70 8.4", TN LCD w/ LED, 8bits/LVDS
    10.1 IVO M101GWT9 R8 1024x600 300 -10~60 10.1", TN LCD w/ LED, 6/8bits/LVDS, 6mm ReplaceableM1012 R1
    10.1 IVO M101GWWF R0 1280x800 350 -20~70 10.1", IPS LCD w/ LED, 8bits/LVDS 亮面 ReplaceableM101B R3
    10.1 IVO M101GWWC R5 800x1280 350 0~60 10.1", IPS LCD w/ LED, MIPI New product
    10.1 IVO M101GW4G R0 1200x1900 350 0~60 10.1", IPS LCD w/ LED, MIPI New product
    10.4 IVO M104GNX1 R1 1024x768 350 -20~70 10.4", TN LCD w/ LED, 6/8 bits/LVDS
    11.6 IVO M116NWR6 R3 1366x768 250 0-50 TN/EDP/30PIN 存储-20-60
    12.1 IVO M121GNS3 R0 800x600 400 -20~70 12.1", TN LCD w/ LED, 6/8 bits/LVDS
    12.1 IVO M121GNX2 R1 1024x768 350 -20~70 12.1", TN LCD w/ LED, 6/8 bits/LVDS
    12.1 IVO M120NN42 R0 2160*1440 400 0-50 全视角IPS/EDP/40PIN 存储-20-60
    12.3 IVO M123AWF4 R0 1920x720 1000 -30~85 12.3", IPS LCD w/ LED, LVDS New product
    15.0 IVO M150GNN2 R1 1024x768 420 -20~70 15.0", TN LCD w/ LED, 8bits/LVDS
  • Size Brand Part No. Resolution L (cd/m^2)(TYP) OperatingTemp(℃) Description Remark Inquiry Download
    10.1 BOE GV101WXM-N85 1280x800 430 -20-70 ADSTFT-LCD/LVDS/40PIN 存储-20-70
    11.6 BOE QV116FHB-N81 1920x1080 NA -20-70 全视角/EDP/30PIN 存储-30-80
    15.6 BOE NT156FHM-N61 1920x1080 220 -0-50 TN/EDP/30PIN 存储-20-60
    15.6 BOE PT156WHM-N10 1366x768 400 -0-50 TN/EDP/30PIN 存储-20-60
    15.6 BOE PV156FHM-N20 1920x1080 400 -0-50 ADS/全视角/EDP/30PIN 存储-20-60
    21.5 BOE HT215F01-100 1920x1080 250 0-50 TN/LVDS/30PIN存储-20~60
  • Size Brand Part No. Resolution L (cd/m^2)(TYP) OperatingTemp(℃) Description Remark Inquiry Download
    21.5 TCL MG2151B05-2 1920x1080 250 -0-50 HVA/LVDS/30PIN 存储-20-60
  • Size Brand Part No. Resolution L (cd/m^2)(TYP) OperatingTemp(℃) Description Remark Inquiry Download
    10.1 CPT FLAA101FAV7 XN 1200*1920 300 -10-50 全视角/MIPI/40PIN 存储-20-60
