Product specifications:

MONO-LCM

市 场 价:¥0

优 惠 价:¥0

库  存:999

选择商品:

商品详细

ZIT is a professional LCD Module design & manufacture company, We can customize any kinds of display contents including Graphic (Dot matrix), Character and Segment (ICON) with different type of LCD Drivers.  Our LCM are applicable for different kinds of LCD , LCM manufacture process and backlight.

The key technology of ZIT’s LCM ( LCD Module ).

※ LCD type: TN, HTN, STN, FSTN, DFSTN, VA, ISTN etc.

※ LCM process: COG, FOG, COB, TAB, SMT etc.

※ LED Backlight color: white, blue, Yellow-Green, Amber, Red, RGB.

※ Connector type: FPC, Metal PIN, PIN header.

    ZIT LCD Module can be used in any application field of display.


Details

ZIT is a professional LCD Module design & manufacture company, We can customize any kinds of display contents including Graphic (Dot matrix), Character and Segment (ICON) with different type of LCD Drivers.  Our LCM are applicable for different kinds of LCD , LCM manufacture process and backlight.

The key technology of ZIT’s LCM ( LCD Module ).

※ LCD type: TN, HTN, STN, FSTN, DFSTN, VA, ISTN etc.

※ LCM process: COG, FOG, COB, TAB, SMT etc.

※ LED Backlight color: white, blue, Yellow-Green, Amber, Red, RGB.

※ Connector type: FPC, Metal PIN, PIN header.

    ZIT LCD Module can be used in any application field of display.


  • Dot matrix
    Resolution
    ZIT LCM
    Part No.
    LCD Mode Operating
    Temperature
    Storage
    Temperature
    LCM
    Size(mm)
    V.A(mm) A.A(mm) Backlight
    Color
    Controller&
    Driver IC
    Inquiry Download
    128*64 ZMAG128641800101 STN/Blue -20~70 -30~80 49.5*49*2.9 46.5*23 40.3*20.14 No UC1701X
    128*64 ZMAG128641800102 STN/Y-G/Transflective -20~70 -30~80 49.5*49*2.9 46.5*23 40.3*20.14 No UC1701X
    128*64 ZMAG128641800103 FSTN/Positive/Transflective -20~70 -30~80 49.5*49*2.9 46.5*23 40.3*20.14 No UC1701X
    192*64 ZMAG192641800201 STN/Y-G -20~70 -30~80 86.4* 41.8 *2.9 82.8* 30.9 76.75 *25.55 No UC1609cGAA
    192*64 ZMAG192641800202 STN/Blue -20~70 -30~80 86.4* 41.8 *2.9 82.8* 30.9 76.75 *25.55 No UC1609cGAA
    192*64 ZMAG192641800203 FSTN/Positive/Transflective -20~70 -30~80 86.4* 41.8 *2.9 82.8* 30.9 76.75 *25.55 No UC1609cGAA
    240*128 ZMAG2401281800301 STN/Blue -20~70 -30~80 86.4*71.2*2.9 80.4*42.4 73.18*39.02 No UC1698U
    240*128 ZMAG2401281800302 STN/Y-G/Transflective -20~70 -30~80 86.4*71.2*2.9 80.4*42.4 73.18*39.02 No UC1698U
    240*128 ZMAG2401281800303 FSTN/Positive/Transflective -20~70 -30~80 86.4*71.2*2.9 80.4*42.4 73.18*39.02 No UC1698U
    240*128 ZMAG2401281800304 FSTN/Positive/Transflective -20~70 -30~80 86.4*71.2*2.9 80.4*42.4 73.18*39.02 No UC1698U
    240*128 ZMAG2401281800305 STN/Gray/Transflective -20~70 -30~80 86.4*71.2*2.9 80.4*42.4 73.18*39.02 No UC1698U
    96*80 ZMAG96801800401 FSTN/Positive/Transflective -20~70 -30~80 31.*40*3.0 28*23.44 27.15*22.59 White UC1612XGAA
    128*128 ZMAG1281281800501 FSTN/Positive/Transflective 0~70 -20~80 33.2*62.28*1.8 27.88*25.84 26.481*24.433 No ST7541-G
    128*128 ZMAG1281281800602 FSTN/Positive/Transflective -20~70 -30~80 33.4*51.7*2 29.4*29.4 28.013*28.013 White ST7571
    128*128 ZMAG1281281800603 FSTN/Positive/Transflective -20~70 -30~80 33.4*51.7*2 29.4*29.4 28.013*28.013 White ST7571
    212*64 ZMAG212641800801 FSTN/Positive/Transflective -10~60 -20~70 114.6*80.5*2.85 108*35 101.74*30.7 No UC1698U
    110*110 ZMAG1101101801001 FSTN/Positive/Transflective -20~70 -30~80 36*49.2*2.3 28.585*28.585 29.585*29.585 White 7571-G4C
    80*80 ZMAG80801801101 FSTN/Positive/Transflective -20~70 -30~80 27*31.5*2.3 24*23.7 22.46*22.46 White UC1612XGAA
    128*64 ZMAG128641801201 FSTN/Positive/Transflective -20~70 -30~80 65*42*2.1 58*31 47.98*27.94 No ST7565R-G












  • Display Content ZIT LCM
    Part No.
    Operating Temperature Storage Temperature LCM Size(mm) V.A(mm) A.A(mm) Controller&
    Driver IC
    Inquiry Download
    8*1 ZMAB811801301 -20~70 -30~80 60*36*13.5 48*13*9 42.6*8.35 SPLC780D
    8*2 ZMAB821801401 -20~70 -30~80 58*32*13.5/9.7 38*16 27.81*11.50 SPLC780D
    16*1 ZMAB1611801501 -20~70 -30~80 80*36*13.5 64.5*13.8 59.42*6.56 SPLC780D
    16*2 ZMAB1621801601 -20~70 -30~80 80*36*11.0 65*17 56.2*11.5 AiP31066
    16*2 ZMAB1621802801 -20~70 -30~80 84*44*14 64.6*16 56.2*11.5 SPLC780D
    16*2 ZMAB1621802601 -20~70 -30~80 80*36*14 64.6*16 56.2*11.5 SPLC780D
    16*2 ZMAB1621802701 -20~70 -30~80 53*24*13.5 38.5*11.5 37.6*10.00 SPLC780D
    16*2 ZMAB1621801801 0~70 -20~80 66*26**max8.5 52*16 16.86*11.5 SPLC780D
    16*2 ZMAB1621801901 -20~70 -30~80 80*36*11/12 64.3*16 55.46*10.76 SPLC780D
    16*2 ZMAB1621802001 -20~70 -30~80 86.5*36*11/12 64.3*16 55.46*10.76 SPLC780D
    16*2 ZMAB1621802701 0~50 -10~60 85*36*max13.5 64.5*15.4 56.21*11.51 ST7066U
    16*2 ZMAB1621803001 -20~70 -30~80 122*44*13.5 99*24 94.8*19.9 SPLC780D
    16*4 ZMAB1641801701 -20~60 -30~70 87*60*12.9 61.6*25 56.2*20.8 SPLC780D
    20*2 ZMAB2021801801 -20~70 -30~80 116*37*14 83*18.3 75.4*11.5 SPLC780D
    20*2 ZMAB2021802301 -20~70 -30~80 180*40*14 148*23 142.78*20.44 SPLC780D
    20*2 ZMAB2021802401 -20~70 -30~80 80*36*13.5 64.5*13.8 27.83*11.50 SPLC780D
    20*4 ZMAB2041801901 -20~70 -30~80 146*62.5*13.6 123.5*43 SPLC780D
    20*4 ZMAB2041802501 -20~70 -30~80 98*60*14 76*26 70.4*20.8 SPLC780D
    20*1 ZMAB2011802001 -20~70 -30~80 116*35*12 82.9*18.5 78.73*7.27 SPLC780D
    20*2 ZMAB2021802101 -20~70 -30~80 146*43*13.5 123*23 118.85*19 SPLC780D
    20*2 ZMAB2021802101 -20~70 -30~80 116*35*12 82.9*18.5 73.51*11.51 SPLC780D
    20*2 ZMAB2021802201 -20~70 -30~80 80*36*8.9 66*16 60.7*11.5 SPLC780D










  • Dot matrix
    Resolution
    ZIT LCM
    Part No.
    Operating
    Temperature
    Storage
    Temperature
    LCM Size(mm) V.A(mm) A.A(mm) Controller&
    Driver IC
    Inquiry Download
    120*32 ZMAB120321803101 -20~70 -30~80 67.35*27.5*13.3 57.5*18.5 53.97*15.33 SBN1661G_M18
    122*32 ZMAB122321803201 -20~70 -30~80 95*44*9 60.0*18.5 53.64*14.04 SBN1661G
    122*32 ZMAB122321803301 -20~70 -30~80 84.0*44.0*13.5 60.0*18.5 53.64*14.04 SBN1661G
    122*32 ZMAB122321803401 -20~70 -30~80 76.4*29.1*6.0 60.8*21.0 48.76*15.32 SBN1661G
    122*32 ZMAB122321803501 -20~70 -30~80 67.0*27.5*8.5 54.8*18.3 48.76*15.32 SBN1661G
    122*32 ZMAB122321803601 -20~70 -30~80 68*31.7*8.6 57.1*17.6 52.41*13.71 ST7920
    122*32 ZMAB122321803701 -20~70 -30~80 80*36*12 64.2*13.8 55.8*12.8
    128*32 ZMAB128321803801 -20~70 -30~80 110*65*13.5 75.9*25.1 72.66*18.14 AiP1107
    128*32 ZMAB128321803901 -20~70 -30~80 59.7*24.8*6.0max 54.5*15.19 51.18*12.78 ST7567
    128*128 ZMAB1281281804001 -20~70 -30~80 38*44.5*4 34*34 31.473*31.473 UC1617S
    144*32 ZMAB144321804101 -20~70 -30~80 80.8*35*max12.5 64.6*16 60.44*13.4 ST7920
    128*64 ZMAB128641804201 -20~70 -30~80 113.0*65.0*13.5 73.4*38.8 64.97*32.46 s6b0108
    128*64 ZMAB128641804301 -20~70 -30~80 78.0*70.0*13.0 62.0*44.0 56.27*38.35 RA6963
    128*64 ZMAB128641804401 -20~70 -30~80 93.0*70.0*13.5 70.7*38.8 66.52*33.24 s6b0108
    128*64 ZMAB128641804401 -20~70 -30~80 54.0*50.0*6.5 43.5*29.0 40.92*24.92 s6b0108
    128*64 ZMAB128641804501 -20~70 -30~80 93*70*12.5 71.8*40 66.52*33.24 ST7920
    128*64 ZMAB128641804601 -20~70 -30~80 61.2*46.5 47.7*36 44.77*30.05
    128*64 ZMAB128641804701 -20~70 -30~80 93*57 65.5*37.8 60.775*32.935
    128*64 ZMAB128641804801 -20~70 -30~80 87*60*max13 73*39 66.52*33.24 ST7920
    128*64 ZMAB128641804901 -20~70 -30~80 80*83*12.5 73*39 66.52*33.24 ST7920
    128*64 ZMAB128641805001 -20~70 -30~80 116*68*max12.5 62*44 56.01*38.35 AiP1107
    128*64 ZMAB128641805101 -20~70 -30~80 78*70*max12.5 62*44 56.01*38.35 AiP1107
    128*64 ZMAB128641805201 -20~70 -30~80 75*52.6*max8.4 60*32 55.01*27.49 AiP1107
    128*64 ZMAB128641805301 -20~70 -30~80 54.2*46.5*max6.5 47.7*36 44.77*30.05 ST7565R
    128*64 ZMAB128641805401 -20~70 -30~80 65*54.5*max6.0 54.6*32 49.89*27.49 ST7567
    128*64 ZMAB128641805501 -20~70 -30~80 93*70*max13.0 71*38 66.5*33.2 ST7567
    128*64 ZMAB128641805601 -20~70 -30~80 87.5*67*max8.0 70*38 66.52*33.24 ST7568R
    128*64 ZMAB128641805601 -20~70 -30~80 87.5*67*max8.0 70*38 66.52*33.24 ST7568R
    160*32 ZMAB160321805701 -20~70 -30~80 107*37.1*12 84*25.7 79.95*21.07 ST7920
    128*64 ZMAB192641805801 -20~70 -30~80 100.0*60.0*13.0 84.0*31.0 78.67*26.19 s6b0108
    192*64 ZMAB192641805901 -20~70 -30~80 130.0*65.0*13.5 104.0*39.0 97.49*32.46 s6b0108
    192*64 ZMAB192641806001 -20~70 -30~80 100*60*12 85*30.5 78.67*26.19 AiP1107
    192*64 ZMAB192641806101 -20~70 -30~80 120*62*12.4 104*39 97.5*32.47 AiP1107
    160*160 ZMAB1601601806201 -20~70 -30~80 83.8*76.5*9.0MAX 60*60 54.38*54.38 uc1698
    160*160 ZMAB1601601806301 -20~70 -30~80 75*82*6.7 67.98*67.98 62.38*62.38 UC1611
    160*160 ZMAB1601601806401 -20~70 -30~80 80*78.5 60*60 54.38*54.38 uc1698
    160*160 ZMAB1601601806401 -20~70 -30~80 88.8*88.8*13.8 62.8*63 60.76*60.76 RA8835
    160*160 ZMAB1601601806501 -20~70 -30~80 82.2*77.5*9.0MAX 60*60 54.38*54.38 uc1698
    160*128 ZMAB1601281806601 -20~70 -30~80 129*102*11.5 101*82.2 92.76*74.2 T6963
    240*64 ZMAB240641806701 -20~70 -30~80 180*65*max12.5 132*39 127.16*33.88 T6963
    240*128 ZMAB2401281806801 -20~70 -30~80 144.0*104.0*14.0 114.0*64.0 107.95*57.55 T 6963
    240*128 ZMAB2401281806901 -20~70 -30~80 159.4*101*9.5 124*70 119.97*63.97 LC7981
    240*128 ZMAB2401281807001 -20~70 -30~80 170*92*9.5 128*74 T6963
    320*128 ZMAB3202401806901 -20~70 -30~80 129*104.5*11.5 101*82.2 92.76*74.2 T6963
    320*240 ZMAB3202401807001 -20~70 -30~80 157.8*121.6*11.5 121*91.6 115.17*86.37 UC0086
    320*240 ZMAB3202401807101 -20~70 -30~80 167*109*13 124*94 115.18*96.38 RA8835
    320*240 ZMAB3202401807201 -20~70 -30~80 139*100*10.5 103*79 95.97*71.97 RA8835
    320*240 ZMAB3202401807301 -20~70 -30~80 160*109*11 122*92 115.17*86.37 RA8835
    320*240 ZMAB3202401807401 -20~70 -30~80 148*120 120.1*92.2 115.17*86.37
    320*240 ZMAB3202401807501 -20~70 -30~80 143*96.8*max13 104*79.3 95.97*71.97 SDN8080G
    320*240 ZMAB3202401807601 -20~70 -30~80 143*96.7*10/12.1 104*79.3 95.98*71.98 RA8835P3N
    320*240 ZMAB3202401807701 -20~70 -30~80 138*98*12 103*79 96.97*71.97 RA8835P3N










  • Display Format Char.xline Model NO. Outline Dimension (W*H)mm Effective ViewingAree (W*H)mm Character Sise (W*h)mm Dot Size (W*H)mm Driving Method (W*H)mm Process Color TN Process Color STN GRAY Process Color STN YELLOW Process Color STN BLUE Process Color FSTN B&W Backlight Page NONE Backlight Page LED Backlight Page LE remarks Inquiry Download
    8*2 ZTC0802A 58.0*32.0 38.0*16.0 2.96*5.56 0.56*0.66 1/16 o o o o o o o replace Winstar product
    8*2 ZTC0802A1 58.0*32.0 38.0*16.0 2.96*5.56 0.56*0.66 1/16 o o o o o o o replace Winstar product
    12*2 ZTC1202A 55.7*32.0 46.0*14.50 2.65*5.50 0.45*0.60 1/16 o o o o o o o replace Winstar product
    16*1 ZTC1601A 80.0*36.0 66.0*16.0 3.07*6.56 0.55*0.75 1/16 o o o o o o o replace Winstar product
    16*1 ZTC1601B 85.0*28.0 66.0*16.0 3.07*6.56 0.55*0.75 1/16 o o o o o o o replace Winstar product
    16*1 ZTC1601L 122.0*33.0 99.0*13.0 4.84*8.06 0.92*1.10 1/16 o o o o o o o replace Winstar product
    16*2 ZTC1602A 84.0*44.0 66.0*16.0 2.95*5.55 0.55*0.65 1/16 o o o o o o o replace Winstar product
    16*2 ZTC1602B 80.0*36.0 66.0*16.0 2.95*5.55 0.55*0.65 1/16 o o o o o o o replace Winstar product
    16*2 ZTC1602C 85.0*36.0 66.0*16.0 2.95*5.55 0.55*0.65 1/16 o o o o o o o replace Winstar product
    16*2 ZTC1602D 85.0*30.0 66.0*16.0 2.95*5.55 0.55*0.65 1/16 o o o o o o o replace Winstar product
    16*2 ZTC1602J 80.0*36.0 66.0*16.0 2.95*5.55 0.55*0.65 1/16 o o o o o o o replace Winstar product
    16*2 ZTC1602L 122.0*44.0 99.0*24.0 4.84*9.66 0.92*1.10 1/16 o o o o o o o replace Winstar product
    16*2 ZTC1602M 85.0*32.6 66.0*16.0 2.95*5.55 0.55*0.65 1/16 o o o o o o o replace Winstar product
    16*2 ZTC1602O 85.0*25.2 66.0*16.0 2.95*5.55 0.55*0.65 1/16 o o o o o o o replace Winstar product
    16*2 ZTC1602P 85.0*25.2 66.0*16.0 2.95*5.55 0.55*0.65 1/16 o o o o o o o replace Winstar product
    16*2 ZTC1602S 59*29.3 52.0*15.3 2.45*4.67 0.45*0.54 1/16 o o o o o o o replace Winstar product
    16*2 ZTC1602T 65.4*28.2 54.8*19.0 3.05*5.57 0.51*0.67 1/16 o o o o o o o replace Winstar product
    16*2 ZTC1602V1 66.7*23.3 61.0*15.9 2.95*5.55 0.55*0.65 1/16 o o o o o replace Winstar product
    16*2 ZTC1602F 72.1*29.6 61.0*15.1 2.95*5.55 0.55*0.65 1/16 o o o o o o o replace Winstar product
    16*4 ZTC1604A/E 87.0*60.0 62.0*26.0 2.95*4.75 0.55*0.55 1/16 o o o o o o o replace Winstar product
    16*4 ZTC1604B 70.6*60.0 60.0*32.6 2.95*4.75 0.55*0.55 1/16 o o o o o o o replace Winstar product
    20*1 ZTC2001A 180.0*40.2 149.0*23.0 6.00*12.715 1.152*1.765 1/16 o o o o o o o replace Winstar product
    20*2 ZTC2002A 116.0*37.0 85.0*18.6 3.2*5.55 0.60*0.65 1/16 o o o o o o o replace Winstar product
    20*2 ZTC2002D 89*21.5 75.0*15.0 2.95*5.15 0.55*0.60 1/16 o o o replace Winstar product
    20*2 ZTC2002L 180.0*40.0 149.0*23.0 6.0*9.66 1.12*1.12 1/16 o o o o o o o replace Winstar product
    20*2 ZTC2002M 146.0*43.0 123.0*23.0 4.84*9.22 0.92*1.10 1/16 o o o o o o o replace Winstar product
    20*4 ZTC2004A/B 98.0*60.0 77.0*25.2 2.95*4.75 0.55*0.55 1/16 o o o o o o o replace Winstar product
    20*4 ZTC2004D 77.0*47.0 60.0*22.0 2.30*4.03 0.42*0.46 1/16 o o o o o o o replace Winstar product
    20*4 ZTC2004L 146.0*62.5 123.5*43.0 4.84*9.22 0.92*1.10 1/16 o o o o o o o replace Winstar product
    24*2 ZTC2402A 118.0*36.0 94.5*16.0 3.2*5.55 0.60*0.65 1/16 o o o o o o o replace Winstar product
    40*2 ZTC4002A 182.0*33.5 154.4*16.5 3.2*5.55 0.60*0.65 1/16 o o o o o o o replace Winstar product
    40*4 ZTC4004A 190.0*54.0 147.0*29.5 2.78*4.89 0.50*0.55 1/16 o o o o o o o o replace Winstar product
  • Display Format Char.xline Model NO. Outline Dimension (W*H)mm Effective ViewingAree (W*H)mm Character Sise (W*h)mm Dot Size (W*H)mm Driving Method (W*H)mm Process Color STN GRAY Process Color STN YELLOW Process Color STN BLUE Process Color STN B&W Backlight Page NONE Backlight Page LED Backlight Page LE Backlight Page CCFL Built-in
    Cibtriller
    remarks Inquiry Download
    122*32 ZTG12232A/C 84.0*44.0 60.0*18.0 0.40*0.45 0.44*0.49 1/32 o o o o o o o SBN1661G replace Winstar product
    122*32 ZTG12232B/G 65.4*29.1 54.8*19.0 0.36*0.41 0.40*0.45 1/32 o o o o SBN1661G replace Winstar product
    122*32 ZTG12232BP1 64.4*28.2 54.8*19.0 0.36*0.41 0.40*0.45 1/32 o o o o SBN1661G replace Winstar product
    122*32 ZTG12232D 59.0*29.3 52.0*15.0 0.345*0.345 0.375*0.375 1/32 o o o o o o SBN1661G replace Winstar product
    122*32 ZTG12232E/J 80.0*36.0 60.0*18.0 0.40*0.45 0.44*0.49 1/32 o o o o o o o SBN1661G replace Winstar product
    122*32 ZTG12232I 59.0*29.3 52.0*15.0 0.345*0.345 0.375*0.375 1/32 o o o o SBN1661G replace Winstar product
    122*32 ZTG12232K 59.0*32.1 52.0*15.0 0.345*0.345 0.375*0.375 1/32 o o o o o o SBN1661G replace Winstar product
    122*32 ZTG12232O 77.8*27.2 60.0*18.0 0.40*0.45 0.44*0.49 1/32 o o o o o o SBN1661G replace Winstar product
    122*32 ZTG12232L 84.0*44.0 60.0*18.0 0.40*0.45 0.44*0.49 1/32 o o o o o o o St7920 replace Winstar product
    122*32 ZTG12232M 65.4*28.2 52.0*19.4 0.345*0.345 0.375*0.375 1/32 o o o o St7920 replace Winstar product
    122*32 ZTG12232N 59.0*29.3 52.0*15.0 0.345*0.345 0.375*0.375 1/32 o o o o o o St7920 replace Winstar product
    128*64 ZTG12864A 93.0*70.0 72.0*40.0 0.48*0.48 0.52*0.52 1/64 o o o o o o o o KS010B replace Winstar product
    128*64 ZTG12864B 75.0*52.7 60*32.6 0.39*0.39 0.43*0.43 1/64 o o o o o o o KS010B replace Winstar product
    128*64 ZTG12864C 78.0*70.0 62.0*44.0 0.42*0.58 0.44*0.60 1/64 o o o o o o KS010B replace Winstar product
    128*64 ZTG12864D 78.0*70.0 62.0*44.0 0.42*0.58 0.44*0.60 1/64 o o o o o o o T6963C replace Winstar product
    128*64 ZTG12864E 54.0*50.0 43.5*29.0 0.28*0.35 0.32*0.39 1/64 o o o o o KS010B replace Winstar product
    128*64 ZTG12864F 87.0*70.0 72.0*40.0 0.48*0.48 0.52*0.52 1/64 o o o o o o T6963C replace Winstar product
    128*64 ZTG12864G 78.0*70.0 62.0*44.0 0.42*0.58 0.44*0.60 1/64 o o o o o o o T6963C replace Winstar product
    128*64 ZTG12864I 80.0*70.0 72.0*40.0 0.48*0.48 0.52*0.52 1/64 o o o o o o o KS010B replace Winstar product
    128*64 ZTG12864U 93.0*70.0 72.0*40.0 0.48*0.48 0.52*0.52 1/64 o o o o o o o T6963C replace Winstar product
    128*64 ZTG12864K 113.0*53.0 72.0*40.0 0.48*0.48 0.52*0.52 1/64 o o o o o o o KS010B replace Winstar product
    128*64 ZTG12864M 95.5*50.2 72.0*40.0 0.48*0.48 0.52*0.52 1/64 o o o o o o o T6963C replace Winstar product
    128*64 ZTG12864S 75.0*52.7 60.0*32.6 0.39*0.39 0.43*0.43 1/64 o o o o o o o T6963C replace Winstar product
    128*128 ZTG128128A 85.0*100.0 62.0*62.0 0.40*0.40 0.43*0.43 1/128 o o o o o o KS010B replace Winstar product
    128*128 ZTG128128B 72.5*69.9 50.0*49.0 0.32*0.32 0.35*0.35 1/128 o o o o o o St7920 replace Winstar product
    128*128 ZTG128128C 65.5*70.0 50.0*49.0 0.32*0.32 0.35*0.35 1/128 o o o o o o KS010B replace Winstar product
    144*32 ZTG14432A 85.0*36.0 66.0*16.0 0.38*0.38 0.42*0.42 1/32 o o o o o o o KS010B replace Winstar product
    144*32 ZTG14432B 80.0*36.0 66.0*16.0 0.38*0.38 0.42*0.42 1/32 o o o o o o o St7920 replace Winstar product
    144*32 ZTG14432C 84.0*44.0 66.0*16.0 0.38*0.38 0.42*0.42 1/32 o o o o o o o St7920 replace Winstar product
    144*32 ZTG14432D 85.5*30.0 66.0*16.0 0.38*0.38 0.42*0.42 1/32 o o o o o o o St7920 replace Winstar product
    144*32 ZTG14432E 80.0*36.0 66.0*16.0 0.38*0.38 0.42*0.42 1/32 o o o o o o o St7920 replace Winstar product
    144*32 ZTG14432F 80.0*36.0 66.0*16.0 0.38*0.38 0.42*0.42 1/32 o o o o o o o St7920 replace Winstar product
    160*32 ZTG16032A 85.2*55.0 74.0*22.0 0.40*0.56 0.44*0.61 1/32 o o o o o o SBN1661G replace Winstar product
    160*32 ZTG16032C 85.2*55.0 74.0*22.0 0.40*0.56 0.44*0.61 1/32 o o o o o o St7920 replace Winstar product
    160*80 ZTG16080A 93.0*70 72.0*40.0 0.39*0.39 0.42*0.42 1/80 o o o o o o o LC79801 replace Winstar product
    160*80 ZTG16080B 93.0*70 72.0*40.0 0.39*0.39 0.42*0.42 1/80 o o o o o o o LC79801 replace Winstar product
    160*80 ZTG16080C 100.0*55.0 72.0*40.0 0.39*0.39 0.42*0.42 1/80 o o o o o o o LC7981 replace Winstar product
    160*128 ZTG160128B 129*102.0 101.0*82.0 0.56*0.56 0.60*0.60 1/128 o o o o o o o o T6963C replace Winstar product
    160*128 ZTG160128C 150*112.0 101.0*82.0 0.56*0.56 0.60*0.60 1/128 o o o o o o o T6963C replace Winstar product
    160*128 ZTG160128E 129*102.0 101.0*82.0 0.54*0.54 0.58*0.58 1/128 o o o o o o o T6963C replace Winstar product
    160*160 ZTG160160A 89.2*85.0 62.0*62.0 0.34*0.34 0.38*0.38 1/160 o o o o o o o NO replace Winstar product
    160*160 ZTG160160B 85.0*100.0 62.0*62.0 0.34*0.34 0.38*0.38 1/160 o o o o o o o LC7981 replace Winstar product
    192*32 ZTG19232B 116.0*37.0 85.0*18.6 0.38*0.46 0.42*0.5 1/32 o o o o o o o St7920 replace Winstar product
    192*32 ZTG19232C 116.0*37.0 85.0*18.6 0.38*0.46 0.42*0.5 1/32 o o o o o o o St7920 replace Winstar product
    192*64 ZTG19264A 130.0*65.0 102.0*39.0 0.46*0.46 0.508*0.508 1/64 o o o o o o KS0107.0108 replace Winstar product
    192*64 ZTG19264C 100.0*60.0 85.0*32.0 0.36*0.36 0.41*0.41 1/64 o o o o o o KS0107.0108 replace Winstar product
    192*64 ZTG19264D 120.06*62.0 102.0*39.0 0.46*0.46 0.50*0.50 1/64 o o o o o o KS0107.0108 replace Winstar product
    192*64 ZTG19264E 150.0*62.5 123.5*43.0 0.59*0.59 0.63*0.63 1/64 o o o o o o NO replace Winstar product
    192*64 ZTG19264F 100.0*60.0 84.0*31.0 0.36*0.36 0.41*0.41 1/64 o o o o o o KS0107.0108 replace Winstar product
    202*32 ZTG20232A 146.0*43 123.0*23.0 0.57*0.57 0.59*0.59 1/32 o o o o o o o SBN1661G replace Winstar product
    202*32 ZTG20232B 146.0*43 123.0*23.0 0.57*0.57 0.59*0.59 1/32 o o o o o o o St7920 replace Winstar product
    240*48 ZTG24048A 133.0*35.0 90.0*21.0 0.32*0.32 0.36*0.36 1/48 o o o o o KS0707.KS0108 replace Winstar product
    240*64 ZTG24064A 180.0*65.0 133.0*39.0 0.49*0.49 0.53*0.53 1/64 o o o o o o o o T6963C replace Winstar product
    240*64 ZTG24064B 180.0*65.0 133.0*39.0 0.49*0.49 0.53*0.53 1/64 o o o o o o o o LC7981 replace Winstar product
    240*64 ZTG24064C 180.0*65.0 133.0*39.0 0.49*0.49 0.53*0.53 1/64 o o o o o o o o T6963C replace Winstar product
    240*64 ZTG24064E 180.0*60.0 131.0*38.0 0.50*0.50 0.53*0.53 1/64 o o o o o o o o T6963C replace Winstar product
    240*64 ZTG24064G 180.0*65.0 133.0*39.0 0.49*0.49 0.53*0.53 1/64 o o o o o o o o RA8822 replace Winstar product
    240*64 ZTG24064J 180.0*65.0 132.6*39.0 0.48*0.48 0.53*0.53 1/64 o o o o o o o o T6963C replace Winstar product
    240*64 ZTG24064R3/R5 180.0*65.0 133.0*39.0 0.49*0.49 0.53*0.53 1/64 o o o o o o o o RA8820 replace Winstar product
    240*128 ZTG240128A 170.0*103.0 132.0*76.0 0.47*0.47 0.50*0.50 1/128 o o o o o o o o T6963C replace Winstar product
    240*128 ZTG240128B 144.0*104.0 114.0*64.0 0.43*0.43 0.45*0.45 1/128 o o o o o o o o T6963C replace Winstar product
    240*128 ZTG240128C 140.0*82.0 114.0*64.0 0.43*0.43 0.45*0.45 1/128 o o o o o o o o RA8820 replace Winstar product
    240*128 ZTG240128D 144.0*104.0 114.0*64.0 0.43*0.43 0.45*0.45 1/128 o o o o o o o o LC7981 replace Winstar product
    240*128 ZTG240128E 144.0*104.0 114.0*64.0 0.43*0.43 0.45*0.45 1/128 o o o o o o o o T6963C replace Winstar product
    240*128 ZTG240128F 170.0*93.6 128.0*75.0 0.47*0.47 0.50*0.50 1/128 o o o o o o o o NO replace Winstar product
    240*128 ZTG240128T 140.0*82.0 114.0*64.0 0.43*0.43 0.45*0.45 1/128 o o o o o o o o RA8806 replace Winstar product
    320*240 ZTG320240A 166.80*109.0 122.0*92.1 0.34*0.34 0.36*0.36 1/240 o o o o o o o o NO replace Winstar product
    320*240 ZTG320240A1 167.0*109.0 122.0*92.1 0.34*0.34 0.36*0.36 1/240 o o o o o o o o NO replace Winstar product
    320*240 ZTG320240B0/BX 160.0*109.0 122.0*92.0 0.34*0.34 0.36*0.36 1/240 o o o o o o o o RA8835/S1D13700 replace Winstar product
    320*240 TG320240B2 160.0*109.0 122.0*92.0 0.34*0.34 0.36*0.36 1/240 o o o o o o o o RA8835 replace Winstar product
    320*240 ZTG320240BP3 160.0*109.0 122.0*92.0 0.34*0.34 0.36*0.36 1/240 o o o o o o o o S1D13700 replace Winstar product
    320*240 ZTG320240C0/CX 148.02*120.24 120.14*92.14 0.34*0.34 0.36*0.36 1/240 o o o o o o o o RA8835/S1D13700 replace Winstar product
    320*240 ZTG320240D 142.0*96.0 104.0*79.3 0.27*0.27 0.30*0.30 1/240 o o o o o o o NO replace Winstar product
    320*240 ZTG320240D1 142.0*96.0 104.0*79.3 0.27*0.27 0.30*0.30 1/240 o o o o o o o o NO replace Winstar product
    320*240 ZTG320240E 143.0*98.0 104.0*79.3 0.28*0.28 0.30*0.30 1/240 o o o o o o o o NO replace Winstar product
    320*240 ZTG320240F 139.0*100.0 104.0*79.3 0.27*0.27 0.30*0.30 1/240 o o o o o o RA8835 replace Winstar product
    320*240 ZTG320240L 160.0*109.9 122.0*92.0 0.34*0.34 0.36*0.36 1/240 o o o o o o o o NO replace Winstar product
    320*240 ZTG320240T3/T5 166.80*109.0 122.0*92.0 0.5*0.49 0.54*0.54 1/240 o o o o o o o o RA8806 replace Winstar product
    320*240 TG320240G 94.7*71.7 81.44*61.0 0.225*0.225 0.24*0.24 1/240 o o o o NO replace Winstar product
    320*240 ZTG320240K 142.0*96.0 104.0*79.3 0.27*0.27 0.30*0.30 1/240 o o o o o o o S1D13700 replace Winstar product
    320*240 ZTG320240N 139.0*100.0 104.0*79.3 0.27*0.27 0.30*0.30 1/240 o o o o o o NO replace Winstar product
    128*64 ZT012864A 60.1*44.5 54.6*32.0 0.36*0.40 0.39*0.43 1/65 o o o o o ST7565P replace Winstar product
    128*64 ZT012864B 73.0*42.0 55.0*30.6 0.37*0.37 0.41*0.41 1/65 o o o o o ST7565P replace Winstar product
    160*160 ZT0160160A 83.8*76.5 60.0*60.0 0.32*0.32 0.34*0.34 1/160 o o o o o UC1698U replace Winstar product
    160*160 ZT0160160C 83.8*76.5 60.0*60.0 0.32*0.32 0.34*0.34 1/160 o o o o o UC1698U replace Winstar product
    320*240 ZT0320240D 94.7*71.7 81.38*60.38 0.225*0.225 0.24*0.24 1/240 o o o o o RA8835 replace Winstar product
    320*240 ZT0320240H 94.7*71.7 81.38*60.38 0.225*0.225 0.24*0.24 1/240 o o o o o RA8835 replace Winstar product
Copyright ©2018-2028 ZIT Technology LimitedTechnical support:Emore
